Cisco D9800 Configuration Guide

Setting the SAP IP Address
Step 1
Do one of the following:
•
Web GUI (single-stream unit): From the D9800 web GUI, choose Transport Stream > MPEG over IP Output.
•
Front Panel (single-stream unit): From the Main Menu of the D9800 front panel, choose Setup > Outputs > TS
Out > MOIP > MOIP Streams.
•
Web GUI (multi-stream unit): From the D9800 web GUI, choose Transport Stream > IP Data 1/Data 2 Output
or Data 3/Data 4 Output.
•
Front Panel (multi-stream unit): From the Main Menu of the D9800 front panel, choose Setup > Outputs > TS
Out > IP > Streams Configuration.
Step 2
In the SAP Multicast IP Address field, or the SAP Address front panel menu, set the Session Announcement Protocol
(SAP) destination IP address. This is the IP address where the SAP announcements are sent, if required.
We recommend that you do not change the default IP address (224.2.127.254).Note
Step 3
In the SAP Destination UDP Port field or SAP Port front panel menu, set the SAP destination port number (1 to 65534).
This is the UDP port where the SAP announcements are sent, if required.
We recommend that you do not change the default SAP port of
9875.
Note
Step 4
Apply the changes.
The front panel has the following additional settings:
•
Send SAP - Select whether to send Session Announcement Protocol messages (None or RFC2327).
•
SAP ID - Choose the SAP output stream name source (User String or SDT Channel).
•
SAP User Str - Enter the SAP user string, up to 31 characters.
Setting the Transport Packet Limits
Step 1
Do one of the following:
•
Web GUI (single-stream unit): From the D9800 web GUI, choose Transport Stream > MPEG over IP Output.
•
Front Panel (single-stream unit): From the Main Menu of the D9800 front panel, choose Setup > Outputs > TS
Out > MOIP > MOIP Streams.
•
Web GUI (multi-stream unit): From the D9800 web GUI, choose Transport Stream > IP Data 1/Data 2 or IP
Data 3/Data 4 Output.
Cisco D9800 Network Transport Receiver Version 3.01 Installation and Configuration Guide
21
Configuring the Transport Stream Information
Setting the SAP IP Address
