Cisco D9800 Configuration Guide

•
Front Panel (single-stream unit): From the Main Menu of the D9800 front panel, choose Setup > Outputs > TS
Out > ASI or MOIP.
•
Web GUI (multi-stream unit): From the D9800 web GUI, choose Transport Stream > ASI 1 Output, ASI 2
Output, IP Data 1/Data 2 Output, or IP Data 3/Data 4 Output.
•
Front Panel (multi-stream unit): From the Main Menu of the D9800 front panel, choose Setup > Outputs > TS
Out > ASI or IP, and choose the input you want to configure from the ASI or IP front panel menu.
Step 2
The Rate Control drop-down list is set to User, as the method used to calculate the output rate. The output rate is specified
by the User Rate field or front panel menu. It is determined by the user setting regardless of the input source.
Step 3
In the User Rate field or front panel menu, choose the maximum output bit rate expected by the equipment connected
to the ASI or MPEGoIP output (0 to 206 Mbps).
The output data may be lost if this bit rate is set to a value less than the actual bit
rate.
Note
Step 4
From the Descrambled drop-down list, or the Descramble Mode front panel menu, choose whether to descramble the
output if the input is descrambled. The following describes the available options:
•
Scrambled - The output channel remains scrambled, even if the PE is authorized and can descramble the channel.
•
Descrambled (default) - Descrambles the output channel, and passes in-the-clear channels.
Step 5
For ASI output, choose Yes or No from the Null Packet Insertion drop-down list, or the Insert Null Packet front panel
menu to determine whether to insert null packets into the output to maintain output at a constant bit rate. Null packets
are always inserted if the configured output bit rate is higher than the payload rate of the transport stream to be encapsulated.
For MPEGoIP output or IP Data output, the Null Packet Insertion drop-down list, or the Insert Null Packet front panel
menu is set to Yes.
Step 6
Apply your changes.
Configuring the ASI or MPEGoIP Output Mode
Step 1
Do one of the following:
•
Web GUI (single-stream unit): From the D9800 web GUI, choose Transport Stream > ASI Output or MPEG
over IP Output.
•
Front Panel (single-stream unit): From the Main Menu of the D9800 front panel, choose Setup > Outputs > TS
Out > ASI or MOIP.
•
Web GUI (multi-stream unit): From the D9800 web GUI, choose Transport Stream > ASI 1 Output, ASI 2
Output, IP Data 1/Data 2 Output, or IP Data 3/Data 4 Output.
Cisco D9800 Network Transport Receiver Version 3.01 Installation and Configuration Guide
4
Configuring the Transport Stream Information
Configuring the ASI or MPEGoIP Output Mode
