Cisco D9800 Configuration Guide

DescriptionOption
The service channel is passed with the same channel number, PMT PIDs, and ES PIDs.
SPTS Service Channels Only
(MPEG over IP only)
The service channel is mapped to the preconfigured channel number, PMT PIDs, and
ES PIDs.
SPTS MAP Service Channels
Only (MPEG over IP only)
The service channel is mapped to the preconfigured channel number, PMT PIDs, and
ES PIDs. The PEs are automatically set to XCode.
SPTS Transcoding
(multi-stream units only)
You are prompted to Resync All for the selected output. This resynchronizes the inputs to outputs for the current PMT
according to the service assignments and the PIDs for the PE.
The Mode Status field, or the Config Type front panel menu, indicates the current DPM configuration change by a user
after changing the Output Mode. The following table lists the statuses:
DescriptionMode Status or Config Type
No changes were made after setting a new output mode.
In a multi-stream unit, this applies to single input mode only. For
more information on single input mode, see Assigning a Channel
to a Program Entry.
In a multi input mode, Unmodified (MS Mode) status is displayed.
Unmodified
DPM changes were made by the user after setting the Output Mode.
In a multi-stream unit, this applies to a single input mode only. For
more information on the single input mode, see Assigning a Channel
to a Program Entry.
In a multi input mode, Edited by User (MS Mode) status is
displayed.
Edited by User
The output map changed automatically to fix the output channel or
PID conflicts at the time of setup.
In a multi-stream unit, this applies to a single input mode only. For
more information on the single input mode, see Assigning a Channel
to a Program Entry.
In a multi input mode, Auto re-mapped (MS Mode) status is
displayed.
Auto Re-Mapped
DPM output changes were made, based on the uplink request after
setting the Output Mode.
In a multi-stream unit, this applies to a single input mode only. For
more information on the single input mode, see Assigning a Channel
to a Program Entry.
In a multi input mode, Chg by Unplink (MS Mode) status is
displayed.
Chg by Uplink
Cisco D9800 Network Transport Receiver Version 3.01 Installation and Configuration Guide
6
Configuring the Transport Stream Information
Configuring the ASI or MPEGoIP Output Mode
