3. After POST is completed, the management module displays the results.
Refresh the window to view the POST results. If the error remains, the
Gigabit Ethernet switch module is defective. Replace the Gigabit Ethernet
switch module.
The
following table describes the basic critical and noncritical failures. This
abbreviated list is representative; it is not intended as an exhaustive list. An
error code is associated with each failure. Error codes appear on the
Management Module Switch Information window. Be sure to note the
applicable error code and corresponding failure. You might have to provide
this information when you call the IBM HelpCenter
®
. For details, see
Chapter 7, “Getting help and technical assistance,” on page 37.
Diagnostic indicator (in
hex)
Failing functional area Failure criticality
00 - 7F Base internal functions Critical
80 - 9F Internal interface failures Noncritical
A0 - AF External interface errors Noncritical
B0 - FE Reserved Noncritical
FF Gigabit Ethernet switch
module “good” indicator
Operation
40 Cisco Systems Intelligent Gigabit Ethernet Switch Module: Installation Guide
