Cisco Firepower 2100 Series Hardware Installation Guide

Figure 39: Install the Cable Management Bracket Screws into the Slide-Rail Locking Bracket
Step 2 Attach the slide-rail locking brackets to each side of the chassis using the six 8-32 x 0.375-inch Phillips screws (three
per side).
Figure 40: Attach the Slide-Rail Locking Bracket to the Side of the Chassis
Slide-rail locking bracket2Chassis1
—8-32 x 0.25-inch Phillips screws (three per side)3
Cisco Firepower 2100 Series Hardware Installation Guide
57
Rack-Mount and Ground the Chassis
Rack-Mount the Chassis Using Slide Rails
