Figure 6: 100-Gb Network Module
100-Gigabit Ethernet QSFP28 fiber port
Ethernet X/1
2Captive screw on handle1
Network activity LEDs
Off—No connection or port is not in use.
Amber—No link or network failure.
Green, flashing—Network activity.
4100-Gigabit Ethernet QSFP28 fiber port
Ethernet X/2
3
Safety Warnings
Take note of the following component replacement safety warnings:
Statement 1028More Than One Power Supply
This unit might have more than one power supply connection. To reduce risk of electric shock,
remove all connections to de-energize the unit.
Warning
Statement 1030Equipment Installation
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Warning
Installation, Maintenance, and Upgrade
14
Installation, Maintenance, and Upgrade
Install, Remove, and Replace the Double-Wide Network Module
