Statement 1073—No User-Serviceable Parts
There are no serviceable parts inside. To avoid risk of electric shock, do not open.
Warning
Statement 1089—Instructed and Skilled Person Definitions
An instructed person is someone who has been instructed and trained by a skilled person and takes
the necessary precautions when working with equipment.
A skilled person or qualified personnel is someone who has training or experience in the equipment
technology and understands potential hazards when working with equipment.
Warning
Statement 1090—Installation by Skilled Person
Only a skilled person should be allowed to install, replace, or service this equipment. See statement
1089 for the definition of a skilled person.
Warning
Statement 1091—Installation by an Instructed Person
Only an instructed person or skilled person should be allowed to install, replace, or service this
equipment. See statement 1089 for the definition of an instructed or skilled person.
Warning
Step 1 To install a new network module for the first time into an empty slot, do the following:
a) Power down the chassis by moving the power switch to the OFF position.
b) Follow Steps 4 through 6 to install the new network module.
c) Power on the chassis by moving the power switch to the ON position.
The state for the new network module is OIR Failed.
d) To change the status of the network module to Online, reboot the chassis. See the "Rebooting the Firepower 4100/9300
Chassis" topic in the System Administration chapter in the FXOS Configuration Guide for your software version.
Step 2 To remove and replace an existing network module, do one of the following:
a) Save your configuration.
b) Power down the chassis by moving the power switch to the OFF position.
c) Continue with Step 3.
Step 3 Do one of the following:
a) If you are removing single-wide network modules installed in the two network module slots, loosen the captive screw
on the left of the network modules, release the handles, and then gently pull the network modules out of the chassis.
Remove the divider between the two network modules by loosening the captive screw at the top of the divider and
then pull it out.
