Figure 13: Install the FIPS Opacity Shield to the Rack-Mount Rails
FIPS opacity shield2Screws1
Rack-mount rails3
Step 3 Unscrew the two captive screws on the front of the access cover to remove the access cover so that you can connect the
cables to the ports.
Installation, Maintenance, and Upgrade
33
Installation, Maintenance, and Upgrade
Install the FIPS Opacity Shield
