Figure 14: Remove the FIPS Access Cover
Access cover2Captive screws1
Step 4 Connect the cables to the ports. See the getting started guides listed in Step 9 for the procedure.
Step 5 Run the cables through the openings on either side of the FIPS opacity shield and reattach the FIPS access cover by
tightening the captive screws.
Installation, Maintenance, and Upgrade
34
Installation, Maintenance, and Upgrade
Install the FIPS Opacity Shield
