Cisco GS7000 User Manual

Reconfiguring Forward Signal Routing
103
Reconfiguring Forward Signal Routing
Introduction
This section describes how to configure the forward signal routing of the 1.2 GHz
GS7000 Node.
Forward Routing Configurations
The receiver modules and the forward configuration module determine the forward
signal routing. Each module must be in its proper slot to achieve the different node
configurations.
The following table shows the required modules and their slot locations for various
node configurations.
If the configuration is…
Then use configuration module…
Install Receivers in
Positions...
one receiver, four outputs
1x4 Forward
1
one receiver, four outputs
(with external RF source)
1x4 Forward with Forward RF
Injection, plus FLI module
1
two receivers, four outputs,
redundant
1x4 Redundant Forward, plus
SM/LCM
1, 2
two receivers, four outputs,
redundant (with external
RF source)
1x4 Redundant Forward with Forward
RF Injection, plus SM/LCM and FLI
module
1, 2
two receivers, each feeding
two outputs, 2-way
segmented
2x4 Forward
1, 3
four receivers, each pair
feeding two outputs, 2-way
segmented, redundant
2x4 Redundant Forward, plus
SM/LCM
1, 2, 3, 4
three receivers, four
outputs
3x4 Forward (for receivers 1, 3, and 4)
1, 3, 4
three receivers, four
outputs
3x4 Forward (for receivers 1, 2, and 4)
1, 2, 4
