Figure 2: Cisco IR1101 Industrial Integrated Services Router
The following graphics show the IR1101 Base Module Front.
Figure 3: Cisco IR1101 Integrated Services Router with USB covers in place
DetailsItem
USB 2.0 Port Cover1
Mini-USB Console Cover2
Product Overview
4
Product Overview
Cisco IR1101 Base Router
