Cisco MDS 9148S Multilayer Switch Hardware Installation Guide
OL-20185-01
Chapter 1 Product Overview
Figure 1 Front View of the Cisco MDS 9148S Multilayer Fabric Switch
The rear of the Cisco MDS 9148S switch contains the redundant power supplies, the AC power receptacle,
and the fans. See Figure 2.
352742
1
2
4
3
6
5
7
1 Console port 5 USB port
2 Status LED 6 Ethernet port
3 Power supply LED 7 Fibre Channel ports
4 FAN LED
