Cisco MDS 9148S Multilayer Switch Hardware Installation Guide
OL-20185-01
Chapter 1 Technical Specifications
SFP Transceiver Specifications
SFP Transceiver Specifications
The Cisco MDS 9148S switch is compatible with SFP transceivers and cables that have LC connectors.
Each transceiver must match the transceiver on the other end of the cable in terms of wavelength, and
the cable must not exceed the stipulated cable length for reliable communications.
Cisco SFP transceivers provide the uplink interfaces, laser transmit (TX), and laser receive (RX), and
they support 850 to 1610 nm nominal wavelengths, depending upon the transceiver.
Use only Cisco SFP transceivers on the Cisco MDS 9148S switch. Each Cisco SFP transceiver is
encoded with model information that enables the switch to verify that the SFP transceiver meets the
requirements for the switch. For the list of supported SFP transceivers, see the release notes.
For details of SFP transceivers see the data sheet at the following location:
http://www.cisco.com/en/US/prod/collateral/ps4159/ps6409/ps4358/product_data_sheet09186a00801b
c698.html
This section provides the following information:
• Cisco Fibre Channel SFP+ Transceivers, page 1-56
• Optical Specifications for Cisco CWDM SFP Transceivers, page 1-60
For information about safety, regulatory, and standards compliance, see the Regulatory Compliance and
Safety Information for the Cisco MDS 9000 Family.
Cisco Fibre Channel SFP+ Transceivers
Table 1-5 lists the Fibre Channel SFP+ transceivers available through Cisco Systems for the
Cisco MDS 9148S switch.
General Specifications for Cisco Fibre Channel 16 Gbps SFP+ Transceivers
Table 1-6 summarizes cabling specifications for 16 Gbps.
Table 1-5 Cisco Fibre Channel SFP + Transceivers for the Cisco MDS 9148S Switch
Part Number Description Type
DS-SFP-FC16G-SW Cisco MDS 4/8/16-Gbps Fibre Channel SW
SFP+, LC
Short wavelength
DS-SFP-FC16G-LW Cisco MDS 4/8/16-Gbps Fibre Channel LW
SFP+, LC
Long wavelength
DS-SFP-FC8G-SW Cisco MDS 2/4/8-Gbps Fibre Channel SW
SFP+, LC
Short wavelength
DS-SFP-FC8G-LW Cisco MDS 2/4/8-Gbps Fibre Channel LW
SFP+, LC
Long wavelength
DS-SFP-FC8G-ER Cisco MDS 2/4/8-Gbps Fibre Channel
Extended Reach SFP+, LC
Extended Reach
DS-CWDM8Gxxxx Cisco MDS 2/4/8-Gbps CWDM Long
Distance SFP, LC
Long Distance
