Cisco NCS-57C3-MOD-SYS User Manual

Figure 37: Install the Chassis in the Rack
Figure 38: Install the Tray to the Rack
Middle slider member2Outer slider member1
Inner slider member3
Step 8 For NC55-2RU-ACC-SL2 with the tray, do the following:
a. Place the chassis on the tray and align the chassis with the screw holes on the tray.
Hardware Installation Guide for Cisco NCS 5700 Series Fixed-Port Routers
50
Install the Chassis
Rack Mount the NCS-57C3-MOD Chassis in a 4-Post Rack using Sliders
