1-27
Cisco Nexus 5000 Series Hardware Installation Guide
Chapter 1 Overview
Cisco Nexus 5500 Platform Switches
This section includes the following topics:
• SFP+ Transceivers, page 1-27
• SFP+ Copper Cables, page 1-28
• SFP Fibre Channel Transceivers, page 1-28
• Cables, page 1-28
SFP+ Transceivers
The enhanced small-form-factor pluggable (SFP+) 10-Gigabit Ethernet transceiver module (see
Table 1-4) is a bidirectional device with a transmitter and receiver in the same physical package. It has
a 20-pin connector on the electrical interface and duplex LC connector on the optical interface.The Cisco
Nexus 5548 switch supports the following SFP+ optical transceivers:
• SR
• LR (for uplink only)
Table 1-3 Supported Transceivers
Cisco SFP Description
FET-10G 10G SFP+ module for Cisco Nexus 2000 Series to Cisco Nexus 5000
Series connectivity
Cisco SFP-10G-SR 10GBASE-SR SFP+ module (multimode fiber [MMF])
Cisco SFP-10G-LR 10GBASE-LR SFP+ module (single-mode fiber [SMF])
Cisco SFP-H10GB-CU1M 10GBASE-CU SFP+ cable 1 m (Twinax cable)
Cisco SFP-H10GB-CU3M 10GBASE-CU SFP+ cable 3 m (Twinax cable)
Cisco SFP-H10GB-CU5M 10GBASE-CU SFP+ cable 5 m (Twinax cable)
Cisco GLC-T 1000BASE-T SFP
Cisco GLC-SX-MM GE SFP, LC connector SX transceiver (MMF)
Cisco GLC-LH-SM GE SFP, LC connector LX/LH transceiver (SMF)
Cisco SFP-GE-T 1000BASE-T SFP, extended temperature range
Cisco SFP-GE-S GE SFP, LC connector SX transceiver (MMF), extended temperature
range and digital optical monitoring (DOM)
Cisco-SFP-GE-L GE SFP, LC connector LX/LH transceiver (SMF), extended temperature
range and DOM
Cisco DS-SFP-FC4G-SW 4-Gbps Fibre Channel SW SFP, LC (for Fibre Channel expansion module
ports)
Cisco DS-SFP-FC4G-LW 4-Gbps Fibre Channel LW SFP, LC (for Fibre Channel expansion module
ports)
Cisco DS-SFP-FC8G-SW 8-Gbps Fibre Channel SW SFP+, LC (for Fibre Channel expansion
module ports)
Cisco DS-SFP-FC8G-LW 8-Gbps Fibre Channel LW SFP+, LC (for Fibre Channel expansion
module ports)
