Cisco Nexus 5000 Series Hardware Installation Guide
Chapter 1 Overview
Cisco Nexus 5500 Platform Switches
SFP+ Copper Cables
Copper cables are available for use with the 10-Gigabit Ethernet SFP+ module (see Table 1-5). The
cables come in the following lengths:
• 1 m, 30 AWG
• 3 m, 28–30 AWG
• 5 m, 26–28 AWG
•
SFP Fibre Channel Transceivers
The Cisco Nexus 5548 switch supports the multimode 850-nm, 4-Gbps SFPs with 150-m reach (see
Table 1-6).
Cables
On the Cisco Nexus 5500 Platforms, you can use an innovative Twinax copper cable that connects to
standard SFP+ connectors for in-rack use and on the optical cable for longer cable runs.
For in-rack or adjacent-rack cabling, the Cisco Nexus 5500 Platform supports SFP+ direct-attach
10-Gigabit Ethernet copper, which integrates transceivers with Twinax cables into an energy efficient,
low-cost, and low-latency solution. SFP+ direct-attach 10-Gigabit Twinax copper cables use only
0.1 W of power per transceiver and introduce only approximately 0.25 microsecond of latency per link.
For longer cable runs, the Cisco Nexus 5500 Platform supports multimode, short-reach optical SFP+
Table 1-4 SFP+ Transceivers
Model Description
SFP-10G-SR 10-Gigabit Ethernet—Short range SFP+ module
SFP-10G-LR 10-Gigabit Ethernet—Long range SFP+ module
Table 1-5 SFP+ Copper Cables
Model Description
SFP-H10GB-CU1M 10GBASE-CU SFP+ cable (1 meter)
SFP-H10GB-CU3M 10GBASE-CU SFP+ cable (3 meters)
SFP-H10GB-CU5M 10GBASE-CU SFP+ cable (5 meters)
Table 1-6 SFP Fibre Channel Transceivers
Model Description
DS-SFP-FC4G-SW 4-Gbps Fibre Channel-SW SFP, LC
DS-SFP-FC4G-LW 4-Gbps Fibre Channel-LW SFP, LC, (10-km reach)
Cisco DS-SFP-FC8G-SW 8-Gbps Fibre Channel SW SFP+, LC
Cisco DS-SFP-FC8G-LW 8-Gbps Fibre Channel LW SFP+, LC
