Cisco Nexus 5000 Series Hardware Installation Guide
Chapter 1 Overview
Cisco Nexus 5000 Platform Switches
SFP+ Copper Cables
Copper cables are available for use with the 10-Gigabit Ethernet SFP+ module (seeTable 1-12). The
cables come in the following lengths:
• 1 m, 30 AWG
• 3 m, 28–30 AWG
• 5 m, 26–28 AWG
SFP Fibre Channel Transceivers
The Cisco Nexus 5010 switch supports the multimode 850-nm 4-Gbps SFP with 150-m reach (see
Table 1-13).
Table 1-12 SFP+ Copper Cables
Model Description
SFP-H10GB-CU1M 10GBASE-CU SFP+ cable (1 meters)
SFP-H10GB-CU3M 10GBASE-CU SFP+ cable (3 meters)
SFP-H10GB-CU5M 10GBASE-CU SFP+ cable (5 meters)
Table 1-13 SFP Fiber Channel Transceivers
Model Description
DS-SFP-FC4G-SW 4-Gbps Fibre Channel-SW SFP, LC
DS-SFP-FC4G-LW 4-Gbps Fibre Channel-LW SFP, LC, (10-km reach)
