• Number 1 manual Phillips torque screwdriver
Step 1 Install the air filter to the front door as follows:
a) Attach the air filter to the front door by aligning the plastic guides on the air filter with the slot holes on the front
door.
Figure 8: Attaching the Air Filter to the Front Door
Snap fit hook on the front door for air filter.3Front door.1
Slot hole on the front door for air filter.4Air filter.2
b) Secure the air filter to the front door by pushing the air filter beyond the plastic snap fit hook on the front door.
Installing the Switch Chassis
14
Installing the Switch Chassis
Attaching the Front Door to the Chassis
