c) Repeat Step 3 to attach the other slider rail to the other side of the rack.
To make sure that the slider rails are at the same level, you should use a level tool, tape measure, or carefully count
the screw holes in the vertical mounting rails.
Step 4 Insert the switch into the rack and attach it as follows:
a) Holding the switch with both hands, position the two rear rack-mount brackets on the switch between the rack or
cabinet posts that do not have slider rails attached to them (see the following figure).
b) Align the two rear rack-mount guides on either side of the switch with the slider rails installed in the rack. Slide the
rack-mount guides onto the slider rails, and then gently slide the switch all the way into the rack until the front
rack-mount brackets come in contact with two rack or cabinet posts.
c) Holding the chassis level, insert screws (12-24 or 10-32, depending on the rack type) in each of the two front rack-mount
brackets (using a total of six screws) and into the cage nuts or threaded holes in the vertical rack-mounting rails (see
the following figure).
Cisco Nexus 93600CD-GX ACI-Mode Switch Hardware Installation Guide
21
Installing the Chassis
Installing the Switch Using the NXK-ACC-KIT-1RU Rack-Mount Kit
