6-22
Cisco PIX Security Appliance Hardware Installation Guide
78-15170-03
Chapter 6 PIX 525
Installing a DC Power Supply
Step 7 Reconnect the two-pin fan cables to the remaining fan, as shown in Figure 6-22.
Figure 6-22 Reconnecting the Fan Cables
31910
Fan
Fan connector
Front panel
