Cisco RV130 User Manual

6 Cisco RV130/RV130W Mutlifunction VPN Router
RV130/RV130W Back Panel
RV130/RV130W Side Panel
USB—Type A USB port on the right side of the housing that supports
3G/4G/LTE USB dongles.
Kensington Lock Slot— Lock slot on the right side to secure the device
physically, using Kensington lockdown equipment (not included).
RESET The RESET button has two functions:
• To reboot the unit and retain the current
configuration, press and hold RESET for at
least 3, but no more than 10 seconds, by using
a paper clip or a pen tip.
• To reboot the unit and restore the factory
default configuration, press and hold the
RESET button for more than 10 seconds.
Changes you have made to the Cisco RV130/
RV130W configuration are lost.
LAN (1-4) RJ-45 device connections to link local area
network devices, such as PCs, print servers, or
switches, to the device.
WAN Internet device connection for connecting the
device to a wide area network device, such as a
cable or DSL modem.
POWER Switch that toggles power to the device on or off.
12VDC Power port that connects the device to the
provided 12VDC power adapter.

Cisco RV130 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Dual-band	No
Ethernet LAN (RJ-45) ports	4
Supported network protocols	PPPoE, PPTP, L2TP, DNS, IGMP, RSTP, NAT, PAT, SIP, ALG
Web-based management	-
Security algorithms	AES
Product color	Black
Certification	FCC, CE, IC
Input current	2 A
Output voltage	12 V
Power source type	DC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	- g
