Cisco RV130 User Manual

Cisco RV130/RV130W Mutlifunction VPN Router 5
WLAN Lit green when the wireless radio is enabled.
Off when the wireless radio is switched off.
Flashes green when transmitting or receiving
data using a wireless connection.
WAN Lit green when the device is connected to the
Internet using a wired connection.
The light is off when the device is not
connected to the Internet or is connected
using a USB dongle.
Flashes green when sending or receiving
data over the wired connection
LAN (1-4) RJ-45 connectors that link local area network
devices, such as PCs, print servers, or
switches, to the device. The numbered lights
correspond to the LAN ports on the back
panel.
Lit green when the corresponding port is
connected to a device.
Flashes green when the port is sending or
receiving data.

Cisco RV130 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Dual-band	No
Ethernet LAN (RJ-45) ports	4
Supported network protocols	PPPoE, PPTP, L2TP, DNS, IGMP, RSTP, NAT, PAT, SIP, ALG
Web-based management	-
Security algorithms	AES
Product color	Black
Certification	FCC, CE, IC
Input current	2 A
Output voltage	12 V
Power source type	DC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	- g
