Figure 13: Removing the Top Cover
Locking cover latch2Top cover1
Serial number label location3
Serial Number Location
The serial number for the server is printed on a label on the top of the server, near the front. See Removing
the Server Top Cover, on page 28.
Hot Swap vs Hot Plug
Some components can be removed and replaced without shutting down and removing power from the server.
This type of replacement has two varieties: hot-swap and hot-plug.
• Hot-swap replacement—You do not have to shut down the component in the software or operating
system. This applies to the following components:
Cisco Application Services Engine Hardware Installation Guide
29
Maintaining the Server
Serial Number Location
