Cisco SF352-08MP Administration Guide

Administration
Plug-n-Play (PNP)
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 87
6
PNP Session
This screen displays the value of the PNP parameters currently in effect. The source of the
parameter is displayed in parenthesis where relevant.
To display information about PNP parameters:
STEP 1 Click Administration > PNP > PNP Session.
The following fields are displayed:
• Administrative Status—Whether PNP is enabled or not.
• Operational Status—Is PNP operational.
• PNP Agent State—Indicates whether there is an active PNP session. The possible
values are Discovery Wait; Discovery; Not Ready; Disabled; Session; Session Wait.
• Transport Protocol– Displays the PNP agent session information.
• TCP Port—TCP port of the PNP session
• Server IP Address—IP address of PNP server
• Username—Username to be sent in PNP packets
• Password MD5—Password to be sent in PNP packets
• Discovery Timeout—Discovery timeout configured
• Session Interval Timeout—Session Interval timeout configured (appears only when
PNP Agent State is Waiting)
• Remaining Timeout—Value of remaining timeout.
NOTE Click the Resume button to immediately take the PnP agent out of the waiting state, in the
following way:
• If the agent is in the Discovery Waiting state, it is set to the Discovery state.
• If the agent is in the PnP Session Waiting state, it is set to the PnP Session state.
