Configuration Wizards
ACL Wizard
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 43
4
STEP 9 Click Next to see the summary of the information that you entered.
STEP 10 Click Apply.
ACL Wizard
To create a new ACL.
STEP 1 Click Configuration Wizards > ACL Wizard.
STEP 2 Click Next.
STEP 3 Enter the fields:
• ACL Name—Enter the name of a new ACL.
• ACL Type—Select the type of ACL: IPv4 or MAC.
STEP 4 Click Next.
STEP 5 Enter the fields:
• Action on match—Select one of the options:
- Permit Traffic—Forward packets that meet the ACL criteria.
- Deny Traffic—Drop packets that meet the ACL criteria.
- Shutdown Interface—Drop packets that meet the ACL criteria, and disable the port
from where the packets received. Such ports can be reactivated from the Error
Recovery Settings page.
STEP 6 For a MAC-based ACL, enter the fields:
• Source MAC Address—Select Any if all source address are acceptable or User defined
to enter a source address or range of source addresses.
• Source MAC Value—Enter the MAC address to which the source MAC address is to
be matched and its mask (if relevant).
• Source MAC Wildcard Mask—Enter the mask to define a range of MAC addresses.
• Destination MAC Address—Select Any if all destination addresses are acceptable or
User defined to enter a destination address or a range of destination addresses.
• Destination MAC Value—Enter the MAC address to which the destination MAC
address is to be matched and its mask (if relevant).
