Smart Network Application (SNA)
DAC Workflow
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 511
25
Specify a RADIUS Server and Clients
STEP 1 Click Edit DAC Mode in the Options menu.
STEP 2 The application enters the DAC edit mode (this is indicated by the blue frame around the
topology map and the control panel on the bottom of the screen.
STEP 3 Select one of the SNA devices and click on its menu.
STEP 4 Designate it as he RADIUS server for the network by clicking + Set as DAC server.
The following menu is displayed:
STEP 5 If the device has more than a single IP address, select one of those addresses as the one to be
used by DAC. The list of addresses indicates whether the IP interface is static or dynamic. You
will be warned if selecting a dynamic interface that the address may not be stable. When
editing an existing DAC server, the address currently used by its clients is pre-selected.
STEP 6 Enter a key string that will be used by the DAC RADIUS server with all its clients on the
network.
STEP 7 Click Done.
The DAC RADIUS server is highlighted in the Topology view.
