Status and Statistics
RMON
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 75
5
After the data is sampled and stored, it appears in the History Table page that can be viewed by
clicking History Table.
To enter RMON control information:
STEP 1 Click Status and Statistics > RMON > History. The fields displayed on this page are defined
in the Add RMON History page, below. The only field is that is on this page and not defined in
the Add page is:
• Current Number of Samples—RMON is allowed by the standard to not grant all
requested samples, but rather to limit the number of samples per request. Therefore, this
field represents the sample number actually granted to the request that is equal or less
than the requested value.
STEP 2 Click Add.
STEP 3 Enter the parameters.
• New History Entry—Displays the number of the new History table entry.
• Source Interface—Select the type of interface from which the history samples are to
be taken.
• Max No. of Samples to Keep—Enter the number of samples to store.
• Sampling Interval—Enter the time in seconds that samples are collected from the
ports. The field range is 1-3600.
• Owner—Enter the RMON station or user that requested the RMON information.
STEP 4 Click Apply. The entry is added to the History Control Table page, and the Running
Configuration file is updated.
STEP 5 Click History Table (described below) to view the actual statistics.
RMON History Table
The History page displays interface-specific statistical network samplings. The samples
configured in the History Control table described above.
To view RMON history statistics:
STEP 1 Click Status and Statistics > RMON > History.
STEP 2 Click History Table.
