VLAN Management
Defining VLAN Membership
Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3 222
13
STEP 4 Enter the values for the following fields:
• Interface—Select a Port or LAG. Select the Unit/Slot on a 500 Series
device.
• Mode—Displays the port VLAN mode that was selected in the Interface
Settings page.
• Select VLAN—To associate a port with a VLAN(s), move the VLAN ID(s) from
the left list to the right list by using the arrow buttons. The default VLAN might
appear in the right list if it is tagged, but it cannot be selected.
• Tagging—Select one of the following tagging/PVID options:
- Forbidden—The interface is not allowed to join the VLAN even from
GVRP registration. When a port is not a member of any other VLAN,
enabling this option on the port makes the port part of internal VLAN
4095 (a reserved VID).
- Excluded—The interface is currently not a member of the VLAN. This is
the default for all the ports and LAGs. The port can join the VLAN through
GVRP registration
- Ta g g e d —Select whether the port is tagged. This is not relevant for
Access ports.
- Untagged—Select whether port is untagged. This is not relevant for
Access ports.
- PVID—Port PVID is set to this VLAN. If the interface is in access mode or
trunk mode, the device automatically makes the interface an untagged
member of the VLAN. If the interface is in general mode, you must
manually configure VLAN membership.
STEP 5 Click Apply. The settings are modified and written to the Running Configuration
file.
STEP 6 To see the administrative and operational VLANs on an interface, click Details.
