VLAN Management
Defining VLAN Membership
221 Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3
13
• PVID—Select to set the PVID of the interface to the VID of the VLAN. PVID is
a per-port setting.
STEP 4 Click Apply. The interfaces are assigned to the VLAN, and written to the Running
Configuration file.
You can continue to display and/or configure port membership of another VLAN
by selecting another VLAN ID.
Configuring VLAN Membership
The Port VLAN Membership page displays all ports on the device along with a list
of VLANs to which each port belongs.
If the port-based authentication method for an interface is 802.1x and the
Administrative Port Control is Auto, then:
• Until the port is authenticated, it is excluded from all VLANs, except guest
and unauthenticated ones. In the VLAN to Port page, the port is marked with
an upper case P.
• When the port is authenticated, it receives membership in the VLAN in
which it was configured.
To assign a port to one or more VLANs:
STEP 1 Click VLAN Management > Port VLAN Membership.
STEP 2 Select interface type (Port or LAG), and click Go. The following fields are
displayed for all interfaces of the selected type:
• Interface—Port/LAG ID.
• Mode—Interface VLAN mode that was selected in the Interface Settings
page.
• Administrative VLANs—Drop-down list that displays all VLANs of which
the interface might be a member.
• Operational VLANs—Drop-down list that displays all VLANs of which the
interface is currently a member.
• LAG—If interface selected is Port, displays the LAG in which it is a member.
STEP 3 Select a port, and click the Join VLAN button.
