Administration: Discovery
Configuring LLDP
Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3 140
9
• Enabled—Enabled Port and Protocol VLAN IDs.
VLAN IDs
• VID—Port and Protocol VLAN ID.
• VLAN Names—Advertised VLAN names.
Protocol IDs
• Protocol ID Table—Advertised protocol IDs.
Location Information
Enter the following data structures in hexadecimal as described in section
10.2.4 of the ANSI-TIA-1057 standard:
• Civic—Civic or street address.
• Coordinates—Location map coordinates—latitude, longitude, and altitude.
• ECS ELIN—Device’s Emergency Call Service (ECS) Emergency Location
Identification Number (ELIN).
• Unknown—Unknown location information.
Network Policies
• Application Type—Network policy application type, for example, Voice.
• VLAN ID—VLAN ID for which the network policy is defined.
• VLAN Type—VLAN type, Tagged or Untagged, for which the network policy
is defined.
• User Priority—Network policy user priority.
• DSCP—Network policy DSCP.
Accessing LLDP Statistics
The LLDP Statistics page
displays LLDP statistical information per port.
To view the LLDP statistics:
