Cisco SG350-10SFP User Manual

Quality of Service
General
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 417
23
General
This section covers the following topics:
• QoS Properties
• Queue
• CoS/802.1p to a Queue
•DSCP to Queue
• Bandwidth
• Egress Shaping per Queue
• VLAN Ingress Rate Limit
•iSCSI
• TCP Congestion Avoidance
QoS Properties
The QoS Properties Page contains fields for setting the QoS mode for the system (Basic,
Advanced, or Disabled, as described in the “QoS Modes” section).
To enable QoS and select the QoS mode:
STEP 1 Click Quality of Service > General > QoS Properties.
STEP 2 Set the QoS mode. The following options are available:
• Disable—QoS is disabled on the device.
• Basic—QoS is enabled on the device in Basic mode.
• Advanced—QoS is enabled on the device in Advanced mode.
STEP 3 Select Port/LAG and click GO to display/modify all ports/LAGs on the device and their CoS
information.
The following fields are displayed for all ports/LAGs:
• Interface—Type of interface.

Cisco SG350-10SFP Specifications

General

Model	SG350-10SFP
Switch Type	Managed
Layer	Layer 3
Switching Capacity	20 Gbps
Forwarding Rate	14.88 Mpps
Power over Ethernet (PoE)	No
Rack Mountable	Yes
Weight	5.51 lbs (2.5 kg)
VLAN Support	Yes
Power Supply	Internal
Jumbo Frame Support	Yes
Management	CLI
Dimensions (W x D x H)	17.32 x 6.89 x 1.73 in (440 x 175 x 44 mm)
Operating Temperature	0° to 40°C (32° to 104°F)
Storage Temperature	-4 to 158°F
Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x
MAC Address Table Size	16, 000 entries
