Cisco SG350-28MP Administration Guide

Administration
Discovery - LLDP
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 91
6
Discovery - LLDP
See Discover - LLDP.
Discovery - CDP
See Discovery - CDP.
Locate Device
This feature enables flashing all network port LEDs on a specific device in the network to
locate the device physically. This feature is useful for locating a device within a room with
many interconnected devices. When this feature is activated, all network port LEDs on the
device flash for a configured duration (one minute by default). In a stacked device, a specific
unit or all units in the stack can be specified.
STEP 1 Click Administration > Locate Device.
STEP 2 Enter values in the following fields:
• Duration—Enter for how long (in seconds) the port’s LEDs will flash.
• Remaining Time—This field is only displayed if the feature is currently activated. It
displays the remaining time during which the LED will flash.
• Unit ID—This field is only displayed when the device is in a stack. Specify the unit on
which the network port LEDs will flash or All for all units.
STEP 3 Click Start to activate the feature.
When the feature is activated the Start button is replaced by the Stop button, which allows you
to stop the LED blinking before the defined timer expires.

Cisco SG350-28MP Specifications

General

Model	SG350-28MP
Total System Ports	28
PoE Ports	24
Switching Capacity	56 Gbps
DRAM	512 MB
Flash Memory	256 MB
Form Factor	Rack-mountable
VLAN Support	Yes
Quality of Service (QoS)	Yes
Security Features	ACLs, 802.1X, Port Security
Power Supply	Internal
MAC Address Table Size	16K entries
Jumbo Frame	9216 bytes
CPU	800 MHz
Layer	Layer 2/Layer 3
Layer 3 Features	Static routing, RIP
Management	Web GUI, CLI, SNMP
Dimensions	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	32°F to 113°F (0°C to 45°C)
Combo Ports (RJ45 + SFP)	2 combo ports
SFP Slots	2 SFP slots
