2 Cisco 350 Series Managed Switches
Welcome
Thank you for choosing the Cisco 350 Series Managed Switches. The
switches are designed to be operational right out-of-the-box as standard
layer 2 and 3 switches. Using the default configuration, your switch
forwards packets between the connecting devices after power up.
This guide familiarizes you with the switch layout and describes how to
deploy the switch in your network. For additional information, see
www.cisco.com/go/350switches.
Package Contents
• Your Cisco 350 Series Managed Switch
• Power Cord
• Rack-Mount Kit and Rubber Feet
• Wall Mounting Package for SF352-08, SF352-08MP, SF352-08P,
SG350-10, SG350-10P, SG350-10MP, or SG350-10SFP
• DB-9 to RJ45 Serial Cable
• Quick Start Guide
• Pointer Card with China RoHS
• Technical Support Contacts
• EU Directives 1999/5/EC Compliance Information (for EU SKU only)
Before You Begin
Before you begin the installation, make sure that you have the following:
• Category 5e or higher RJ-45 Ethernet cables for connecting network
devices.
• Console cable for using the console port to manage your switch.
• Tools for installing the hardware. The rack-mount kit packed with the
switch contains four rubber feet for desktop placement, and two
brackets and twelve screws for rack-mounting. If the supplied screws
are lost, use replacement screws in the following size:
– Diameter of the screw head: 6.9 mm
– Length of face of screw head to base of screw: 5.9 mm
– Shaft diameter: 3.94 mm
• The wall mount kit includes screws and anchors. If the supplied screws
are lost, use replacement screws in the following size:
