Cisco SG350-28MP User Manual

4 Cisco 350 Series Managed Switches
To install the switch into a 19-inch standard chassis:
STEP 1 Place one of the supplied brackets on the side of the switch so that
the four holes of the brackets align to the screw holes, and then use
the four supplied screws to secure it.
STEP 2 Repeat the previous step to attach the other bracket to the opposite
side of the switch.
STEP 3 After the brackets are securely attached, the switch is now ready
to be installed into a standard 19-inch rack.
Wall Mounting
Most of the 350 Series Cisco switches include wall-mounting slots on the
bottom of the device.
WARNING Insecure mounting may damage the device or cause injury.
Cisco is not responsible for damages incurred by insecure wall
or ceiling mounting.
To mount your switch to a wall:
STEP 1 Determine where you want to mount the device. Verify that the
surface is smooth, flat, dry, and sturdy.
STEP 2 Drill two pilot holes into the surface of the wall 94 mm apart.
STEP 3 Insert a screw into each hole, leaving a gap between the surface
and the base of the screw head.
400925

Cisco SG350-28MP Specifications

General

Model	SG350-28MP
Total System Ports	28
PoE Ports	24
Switching Capacity	56 Gbps
DRAM	512 MB
Flash Memory	256 MB
Form Factor	Rack-mountable
VLAN Support	Yes
Quality of Service (QoS)	Yes
Security Features	ACLs, 802.1X, Port Security
Power Supply	Internal
MAC Address Table Size	16K entries
Jumbo Frame	9216 bytes
CPU	800 MHz
Layer	Layer 2/Layer 3
Layer 3 Features	Static routing, RIP
Management	Web GUI, CLI, SNMP
Dimensions	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	32°F to 113°F (0°C to 45°C)
Combo Ports (RJ45 + SFP)	2 combo ports
SFP Slots	2 SFP slots
