Administration: File Management
File Operations
81 Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x
6
- If the server is selected by name in the Server Definition, there is no need to select
the IP Version related options.
- IPv6 Address Type—Select the IPv6 address type (if used). The options are:
Link Local—The IPv6 address uniquely identifies hosts on a single network link. A
link local address has a prefix of FE80, is not routable, and can be used for
communication only on the local network. Only one link local address is supported.
If a link local address exists on the interface, this entry replaces the address in the
configuration.
Global—The IPv6 address is a global Unicast IPV6 type that is visible and
reachable from other networks.
- Link Local Interface—Select the link local interface from the list.
• Server IP Address/Name—Enter the IP address or name of the TFTP server.
• Source—Enter the update file name.
STEP 3 Click Apply to begin the operation.
To update a system configuration file using SCP:
STEP 1 Click Administration > File Management > File Operations.
STEP 2 Enter the following fields:
• Operation Type—Select Update File.
• Destination File Type—Select one of the configuration file types to update.
• Copy Method—Select SCP.
STEP 3 To enable SSH server authentication (which is disabled by default), click Edit by Remote
SSH Server Authentication. This takes you to the SSH Server Authentication page to
configure the SSH server
STEP 4 Return to this page.
STEP 5 Select one of the following methods to perform SSH Client Authentication:
• Use SSH Client System Credentials—Sets permanent SSH user credentials. Click
System Credentials to go to the SSH User Authentication page where the user/
password can be set once for all future use.
• Use SSH Client One-Time Credentials—Enter the following:
