Smart Network Application (SNA)
Right-Hand Information Panel
Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x 661
29
The following information is displayed for a client (end point device, such as a PC):
Last seen The date and time the device was last
seen by SNA in the format of the active
language file.
English language file
example:
2015-Nov-04 17:17:53
Parameter Name Notes Example
Host Name String of a maximum of 58 characters RND_1
IP Address Shows the IP address used by SNA to
connect to the device. Additional
advertised addresses (IPv4 and IPv6)
can be seen by clicking an icon next to
the label.
192.168.1.55
923:a8bc::234
MAC Address The base MAC address of the device 00:00:b0:83:1f:ac
Device Type The type of client device Phone
Host
Unknown
Connected
Interface
The interface through which the
device is reached on the closest switch
GE1/14
The following parameters only appear when View all is clicked:
Connection
Speed
100M
10G
VLAN
Membership
Shows the active VLANs of which the
connected interface is a member.
Dashes are used to join consecutive
VLANs.
1, 6, 13-19, 1054, 2012-2100,
4094
Port Utilization
% (Tx/Rx)
Based on the information from the
connected port.
80/42
PoE Power
Consumption
Appears only if the client is connected
to a PoE port.
8900 mW
Parameter Name Notes Example
