Cisco SGE2000 Administration Guide

Appendix
E
61
Appendix E: Specifications
Linksys One Ready Communications Solution
Layer 2
options
• MAC table size - 8K
• Number of VLANs - 256 active VLANs (4096 range)
•VLAN
- Port-based and 802.1Q Tag-based VLANs
- Protocol-based VLAN, Management VLAN
- Private VLAN Edge (PVE)
- GARP VLAN Registration Protocol (GVRP)
• Head of line blocking prevention
Layer 3
options
• Static Routing
• CIDR (Classless Interdomain Routing)
•128 Static Routes
•IPv4
• Forwarding in silicon - Wirespeed forwarding of layer 3 traffic
Environment • Operation Temperature: 0 to 40°C, 32 to 104°F
• Storage Temperature: -20 to 70°C, -4 to 158°F
• Operating Humidity 10% to 90% relative humidity, Non-
Condensing
• Storage Humidity 10% to 95% relative humidity, Non-Condensing
Web User
Interface
Built-in Web UI for easy browser-based configuration (HTTP/HTTPS)
SNMP SNMP version 1, 2c, 3 with support for traps
SNMP MIBs • SNMP version 1, 2c, 3 with support for traps
• RFC1213 MIB-2, RFC2863 Interface MIB, RFC2665 Ether-like
MIB, RFC1493 Bridge MIB, RFC2674 Extended Bridge MIB (P-
bridge, Q-bridge), RFC2819 RMON MIB (groups 1,2,3,9 only),
RFC2737 Entity MIB, RFC3621 Power Ethernet MIB, RFC 2618
RADIUS Client MIB RFC 1215 Traps
Firmware
Upgrade
• Web Browser upgrade (HTTP) and TFTP
• Dual images for resilient firmware upgrades
Port
Mirroring
Traffic on a port can be mirrored to another port for analysis with a
network analyzer or RMON probe

Cisco SGE2000 Specifications

General

Jumbo Frame Support	9KB
VLANs	Up to 256
Management	Web-based, SNMP, CLI
Standards	IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.1D, 802.1Q, 802.1p, 802.1w
Dimensions	440 x 44 x 257 mm
Power Supply	100 to 240V AC, 50-60 Hz
Operating Temperature	0°C to 40°C
Storage Temperature	-20 to 70°C (-4 to 158°F)
Humidity	10% to 90% non-condensing
Weight	3.2 kg
