What to Do Next
Install the Cable Management Arm (Optional)
The CMA is reversible left to right. To reverse the CMA, see Reversing the Cable Management Arm
(Optional) before installation.
Note
Step 1
With the server pushed fully into the rack, slide the CMA tab of the CMA arm that is farthest from the server onto the
end of the stationary slide rail that is attached to the rack post (see the following figure). Slide the tab over the end of
the rail until it clicks and locks.
Step 2
Slide the CMA tab that is closest to the server over the end of the inner rail that is attached to the server (see the following
figure). Slide the tab over the end of the rail until it clicks and locks.
Step 3
Pull out the width-adjustment slider that is at the opposite end of the CMA assembly until it matches the width of your
rack (see the following figure).
Step 4
Slide the CMA tab that is at the end of the width-adjustment slider onto the end of the stationary slide rail that is attached
to the rack post (see the following figure). Slide the tab over the end of the rail until it clicks and locks.
Step 5
Open the hinged flap at the top of each plastic cable guide and route your cables through the cable guides as desired.
Figure 8: Attach the Cable Management Arm to the Rear of the Slide Rails
Cisco Identity Services Engine Hardware Installation Guide, Release 2.0.1
19
Install Cisco ISE Software on the SNS 3515 and SNS 3595 Appliances
Install the Cisco SNS 3515 or 3595 Appliance in a Rack
