Cisco TelePresence SX20 Codec API Reference Guide
Events
Event returns information about the events that are available
for feedback. This overview presents examples of some the
events that are available on the API.
To get an overview of the supported events type ?, ?? or help
after xEvent:
• xEvent ? Lists the top level events
• xEvent ?? List all of the available events
• xEvent help Lists the top level events
The result for events depends on the state of the codec.
Example 1: Outgoing Call Indication
Outgoing Call Indication is an event reported when an
outgoing call is about to be dialled. Returns the CallId the call
has been assigned.
*e OutgoingCallIndication CallId: x
** end
Example 2: Call Disconnect
Call Disconnect is an event reported when a call is
disconnected. Returns the CallId of the disconnected call and
reason for the call’s disconnection.
*e CallDisconnect CallId: x CauseValue: 0
CauseString: “” CauseType: LocalDisconnect
OrigCallDirection: “outgoing”
** end
Example 3: Call Successful
Call Succesful is an event reported when a call is connected
successfully, that is when all channels are up and established.
*e CallSuccessful CallId: 132 Protocol: “h223”
Direction: “outgoing” CallRate: 768 RemoteURI:
“h223:integratorHQ@company.com” EncryptionIn:
“Off” EncryptionOut: “Off”
** end
Example 4: FECC Action request
FECC Action request is an event reported when far end is
sending FECC commands.
*e FeccActionInd Id: 132 Req: 1 Pan: 1 PanRight:
1 Tilt: 0 TiltUp: 0 Zoom: 0 ZoomIn: 0 Focus: 0
FocusIn: 0 Timeout: 300 VideoSrc: 0 m: 0
** end
