Cisco UCS 5108 Blade Server Chassis
32
SUPPLEMENTAL MATERIAL
For the B200 M3 blade server, supported card adapter combinations are shown in Table 18.
The general connectivity diagrams between the adapter cards and the different fabric extenders are shown
in
Figure 17 on page 33 through Figure 19 on page 34.
Table 18 Adapter Card Options
Fabric
Extender
Compatibility
Adapter in VIC 1240 Connector Adapter in Mezzanine Connector
Ports
1
1. Cisco-designed adapters are capable of port channeling. A port channel bundles up to four individual
interfaces into a group to provide increased bandwidth and redundancy. Port channeling also load balances
traffic across these physical interfaces. The port channel stays operational as long as at least one physical
interface within the port channel is operational. Cisco-certified adapters suppled by third-party vendors do
not support port channeling. Port channeling is indicated with an oval drawn around several individual ports.
2208XP
2208XP VIC 1240 None 4 x 10 Gb
2208XP VIC 1240 VIC 1280 8 x 10 Gb
2208XP VIC 1240
Cisco-certified mezzanine adapter
2
2. Cisco-certified mezzanine adapters are manufactured by third-party vendors and are certified by Cisco for use
in the servers. For more information about supported Cisco-certified mezzanine adapters, see
http://www.cisco.com/en/US/docs/unified_computing/ucs/hw/chassis/install/blade.html#wp1010426
6 x 10 Gb
2208XP VIC 1240 Port Expander Card for VIC 1240 8 x 10 Gb
2208XP None Cisco-certified mezzanine adapter 2 x 10 Gb
2204XP
2204XP
VIC 1240 None 2 x 10 Gb
2204XP
VIC 1240 VIC 1280 4 x 10 Gb
2204XP
VIC 1240 Cisco-certified mezzanine adapter 4 x 10 Gb
2204XP
VIC 1240 Port Expander Card for VIC 1240 4 x 10 Gb
2204XP
None Cisco-certified mezzanine adapter 2 x 10 Gb
2104XP
2104XP VIC 1240
None
3
3. The 2104XP fabric extender is not compatible with any I/O card installed in the mezzanine connector.
2 x 10 Gb
