Cisco UCS 5108 Blade Server Chassis
4
DETAILED VIEWS
DETAILED VIEWS
Chassis Front Views
Figure 3 is a detailed front view of the Cisco UCS 5108 Blade Server Chassis with eight half-width blade
servers installed.
Figure 3 5108 Chassis Front View With Eight Half-Width Blade Servers Installed
Table 1 Front View Callouts
Callout Description
Slot 1 - 8 Slot numbering for half-width blade servers
Power Supply 1 - 4 4 x 2500 W power supplies
Slot 1
Slot 3
Slot 5
Slot 7
Power Supply 1 Power Supply 2 Power Supply 3 Power Supply 4
Slot 2
Slot 4
Slot 6
Slot 8

Cisco UCS 2208XP Specifications

General

Brand	Cisco
Model	UCS 2208XP
Category	Chassis
Language	English
