Cisco UCS B200 M3 Installation And Service Note

Table 3: Supported DIMM Population Order
CPU 2 installed slotsCPU 1 installed slotsDIMMs per CPU
E0A01
E0, F0A0, B02
E0, F0, G0A0, B0, C03
E0, F0, G0, H0A0, B0, C0, D04 (Blue slots)
E0, F0, G0, H0, E1A0, B0, C0, D0, A15
E0, F0, G0, H0, E1, F1A0, B0, C0, D0, A1, B16
E0, F0, G0, H0, E1, F1, G1A0, B0, C0, D0, A1, B1, C17
E0, F0, G0, H0, E1, F1, G1, H1A0, B0, C0, D0, A1, B1, C1, D18 (Blue and black slots)
E0, F0, G0, H0, E1, F1, G1, H1, E2A0, B0, C0, D0, A1, B1, C1, D1,A29
E0, F0, G0, H0, E1, F1, G1, H1, E2, F2A0, B0, C0, D0, A1, B1, C1, D1,A2, B210
E0, F0, G0, H0?E1, F1, G1, H1, E2, F2,
G2
A0, B0, C0, D0, A1, B1, C1, D1,A2, B2, C211
E0, F0, G0, H0, E1, F1, G1, H1, E2, F2,
G2, H2
A0, B0, C0, D0?A1, B1, C1, D1,A2, B2, C2,
D2
12 (Blue, black and beige slots)
Memory Performance
When considering the memory configuration of your blade server, there are several things you need to consider. For example:
•
When mixing DIMMs of different densities, the highest density DIMM goes in slot 1 then in descending density.
•
Your selected CPU(s) can have some affect on performance.
•
DIMMs can be run in a 1DPC, a 2DPC, or a 3DPC configuration. 1 DPC and 2DPC can provide the maximum rated speed that
the CPU and DIMMs are rated for. 3DPC causes the DIMMs to run at a slower speed.
Memory Mirroring and RAS
The Intel CPUs within the blade server support memory mirroring only when an even number of Channels are populated with DIMMs.
If one or three channels are populated with DIMMs, memory mirroring is automatically disabled. Furthermore, if memory mirroring
is used, DRAM size is reduced by 50 percent for reasons of reliability.
28

Cisco UCS B200 M3 Specifications

General

System bus rate	8 GT/s
Processor family	Intel
Processor socket	LGA 2011 (Socket R)
Intel Xeon series	E5-2600
Motherboard chipset	Intel C600
Compatible processor series	Intel® Xeon®
Number of processors supported	2
ECC	Yes
Memory form factor	240-pin DIMM
Number of DIMM slots	24
Supported memory types	DDR3-SDRAM
Maximum internal memory	768 GB
RAID levels	0, 1
Storage drive sizes supported	2.5 \
Supported storage drive interfaces	Serial Attached SCSI (SAS), Serial ATA III
USB 2.0 ports quantity	0
On-board graphics card model	Matrox G200
Chassis type	-
Product color	Silver
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	5 - 93 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	620 mm
Width	203 mm
Height	50 mm
Weight	4360 g
