Cisco UCS C220 M3 Installation And Service Guide

C-5
Cisco UCS C220 Server Installation and Service Guide
OL-25760-01
Appendix C RAID Controller Considerations
Factory-Default Option ROM Settings
Factory-Default Option ROM Settings
Table C-4 describes the option ROM (OPROM) settings for card slots that are made at the factory for
various configurations. The version of the se
rver and the number of CPUs affect the OPROM settings.
Note If an option is listed as “not allowed” in Table C-4, that is because it is not supported in the particular
configuration described in that table row. See the footnotes below the table for more information.
For additional information about RAID controller support, see Supported RAID Controllers and
Required Cables, page C-2.
Ta b l e C-4 Cisco UCS C220 Factory-Default Option ROM Settings
Server Version
Number
of CPUs
Embedded
SW
RAID
Enabled?
Mezz. RAID
Controller
Installed?
PCIe RAID
Controller 1
Installed?
PCIe RAID
Controller 2
Installed?
LOM
por
ts Comments
C220 SFF 8 HDD/
C2
20 LFF 4 HDD
1 Enabled Not allowed
1
1. You cannot use the embedded SW RAID and HW RAID (mezzanine or PCIe card) at the same time.
Not allowed Not allowed Always
enabled
All other OPROM
is disabled.
C220 SFF 8 HDD/
C2
20 LFF 4 HDD
1 Not allowed Not allowed
2
2. In single-CPU configurations, the mezzanine card slot is not supported.
Installed: 
PCIe slot 1
enabled
3
3. In single-CPU configurations, PCIe slot 2 is not available.
Not allowed Always
enabled
All other OPROM
is disabled.
C220 SFF 8 HDD/
C2
20 LFF 4 HDD
2 Enabled Not allowed Not allowed Not allowed Always
enabled
All other OPROM
is disabled.
C220 SFF 8 HDD/
C2
20 LFF 4 HDD
2 Not allowed Installed: 
connector
en
abled
Not allowed
4
4. You cannot mix controller types in a server. A PCIe-style controller cannot be used when a mezzanine-style controller is used.
Not allowed Always
enabled
All other OPROM
is disabled.
C220 SFF 8 HDD/
C2
20 LFF 4 HDD
2 Not allowed Not allowed
5
5. You cannot mix controller types in a server. A mezzanine-style controller cannot be used when a PCIe-style controller is used.
Installed: 
PCIe slot 2
en
abled
Not allowed Always
en
abled
All other OPROM
is disabled.

Cisco UCS C220 M3 Specifications

General

Tcase	70 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor cache	10 MB
Processor cores	4
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor codename	Sandy Bridge EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	52.5 x 45.0 mm
Processor front side bus	- MHz
Processor boost frequency	2.50 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Graphics & IMC lithography	32 nm
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	24
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	750 GB
HDD size	2.5 \
HDD interface	-
Total storage capacity	500 GB
Compatible memory cards	SD
Maximum storage capacity	- TB
Memory slots	16
Internal memory	32 GB
Memory clock speed	1866 MHz
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Chassis type	Rack (1U)
Power supply	450 W
Safety	UL 60950-1 No. 21CFR1040, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, GB4943 2001
Certification	47CFR Part 15 (CFR 47), AS/NZS CISPR22, CISPR2 2, EN55022, ICES003, VCCI, EN61000-3-2, EN61000-3-3, KN22, CNS13438, EN55024, CISPR24, EN300386, KN24
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
PCI Express slots version	3.0
Processor ARK ID	64588
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	724 mm
Width	430 mm
Height	43.2 mm
