Chapter 3 Maintaining the Server
Installing or Replacing Server Components
Replacing CPUs and Heatsinks
This section contains the following topics:
• Special Information For Upgrades to Intel E5-2600 v2 Series CPUs, page 3-23
• CPU Configuration Rules, page 3-23
• CPU Replacement Procedure, page 3-24
• Additional CPU-Related Parts To Order With RMA Replacement Motherboards, page 3-29
Special Information For Upgrades to Intel E5-2600 v2 Series CPUs
Caution You must upgrade your server firmware to the required minimum level before you upgrade to Intel
E5-2600 v2 Series CPUs. Older firmware versions cannot recognize the new CPUs and this results in a
non-bootable server.
The minimum software and firmware versions required for the server to support Intel E5-2600 v2 Series
CPUs are as follows:
Do one of the following actions:
• If your server’s firmware and/or Cisco UCS Manager software are already at the required levels
shown in Table 3-6, you can replace the CPU hardware by using the procedure in this section.
• If your server’s firmware and/or Cisco UCS Manager software is earlier than the required levels, use
the instructions in the Cisco UCS C-Series Servers Upgrade Guide for Int
el E5-2600 v2 Series CPUs
to upgrade your firmware. After you upgrade the software, retu
rn to the procedure in this section to
replace the CPU and heatsink hardware.
CPU Configuration Rules
This server has two CPU sockets. Each CPU supports four DIMM channels (eight DIMM slots). See
Figure 3-12.
• The server can operate with one CPU or two identical CPUs installed.
• The minimum configuration is that the server must have at least CPU1 installed. Install CPU1 first,
then CPU2.
Note The following restrictions apply when using a single-CPU configuration: the maximum number
of DIMMs is eight, the internal mezzanine card slot is unavailable, and PCIe slot 2 is unavailable
(see Figure 3-20).
Ta b l e 3-6 Minimum Requirements For Intel E5-2600 v2 Series CPUs
Software or Firmware Minimum Version
Server CIMC 1.5(3)
Server BIOS 1.5(3)
Cisco UCS Manager
(UCSM-managed syst
em only)
2.1(3)

Cisco UCS C220 M3 Specifications

General

Tcase	70 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor cache	10 MB
Processor cores	4
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor codename	Sandy Bridge EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	52.5 x 45.0 mm
Processor front side bus	- MHz
Processor boost frequency	2.50 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Graphics & IMC lithography	32 nm
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	24
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	750 GB
HDD size	2.5 \
HDD interface	-
Total storage capacity	500 GB
Compatible memory cards	SD
Maximum storage capacity	- TB
Memory slots	16
Internal memory	32 GB
Memory clock speed	1866 MHz
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Chassis type	Rack (1U)
Power supply	450 W
Safety	UL 60950-1 No. 21CFR1040, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, GB4943 2001
Certification	47CFR Part 15 (CFR 47), AS/NZS CISPR22, CISPR2 2, EN55022, ICES003, VCCI, EN61000-3-2, EN61000-3-3, KN22, CNS13438, EN55024, CISPR24, EN300386, KN24
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
PCI Express slots version	3.0
Processor ARK ID	64588
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	724 mm
Width	430 mm
Height	43.2 mm
