Cisco UCS C220 M3 Installation And Service Guide

3-41
Cisco UCS C220 Server Installation and Service Guide
OL-25760-01
Chapter 3 Maintaining the Server
Installing or Replacing Server Components
Enabling a Cisco Flexible Flash Virtual Drive
Each of the VDs on the pre-installed Cisco Flexible Flash card can be separately enabled or hidden from
the host. The default as shipped from the factory is for all VDs to be hidden.
To enable VDs and expose them to th
e host, follow these steps:
Step 1 Log in to CIMC interface for the server, using the IP address of the server.
Step 2 Navigate through GUI tabs to Server > Inventory > Storage.
Step 3 Click FlexFlash-0 in the Storage Adapters list.
Step 4 Click on Configure Operational Profile in the Actions area.
The Operational Profile dialog opens.
Step 5 Check the box for each VD that you want to enable and expose to the host, then click Save Changes.
Booting a Cisco Flexible Flash Virtual Drive
When you want to access the Cisco SCU or Cisco HUU software, you boot its VD with a one-time boot
option. When you want to boot the hypervisor (HV) VD, you boot it with a permanent boot order
selection. See the following topics in this section:
• Booting the Cisco SCU and Cisco HUU Software VDs, page 3-41
• Booting the Hypervisor VD, page 3-41
Booting the Cisco SCU and Cisco HUU Software VDs
You can access the preinstalled Cisco SCU and Cisco HUU software bundles on a Cisco Flexible Flash
card by booting their respective VDs with a one-time boot option:
Step 1 Enable the SCU or HUU VD.
See Enabli
ng a Cisco Flexible Flash Virtual Drive, page 3-41.
Step 2 In the CIMC GUI interface, navigate through the tabs to Server > BIOS.
Step 3 Click Configure Boot Override Priority.
The Boot Override Priority dialog opens.
Step 4 Pull down the menu and select SCU or HUU, then click OK.
Step 5 Reboot the server.
The server boots the selected VD.
Note This is a one-time boot option. After running Cisco SCU or Cisco HUU, the server returns to its
previously configured boot path.
Booting the Hypervisor VD
You can boot the hypervisor (HV) VD with a more permanent boot selection. (To change the boot order
one time, use the procedure in Booting the Cisco SCU and Cisco HUU Software VDs, page 3-41.

Cisco UCS C220 M3 Specifications

General

Tcase	70 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor cache	10 MB
Processor cores	4
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor codename	Sandy Bridge EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	52.5 x 45.0 mm
Processor front side bus	- MHz
Processor boost frequency	2.50 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Graphics & IMC lithography	32 nm
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	24
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	750 GB
HDD size	2.5 \
HDD interface	-
Total storage capacity	500 GB
Compatible memory cards	SD
Maximum storage capacity	- TB
Memory slots	16
Internal memory	32 GB
Memory clock speed	1866 MHz
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Chassis type	Rack (1U)
Power supply	450 W
Safety	UL 60950-1 No. 21CFR1040, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, GB4943 2001
Certification	47CFR Part 15 (CFR 47), AS/NZS CISPR22, CISPR2 2, EN55022, ICES003, VCCI, EN61000-3-2, EN61000-3-3, KN22, CNS13438, EN55024, CISPR24, EN300386, KN24
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
PCI Express slots version	3.0
Processor ARK ID	64588
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	724 mm
Width	430 mm
Height	43.2 mm
