Cisco UCS C220 M3 Installation And Service Guide

3-37
Cisco UCS C220 Server Installation and Service Guide
OL-25760-01
Chapter 3 Maintaining the Server
Installing or Replacing Server Components
g. Replace the server in the rack, replace cables, and then power on the server by pressing the Power
button.
h. If the card that you replaced was a RAID controller, continue with Restoring RAID Configuration
After Replacing a RAID Controller, page C-23.
Special Considerations for Cisco UCS Virtual Interface Cards
Table 3-8 describes the requirements for the supported Cisco UCS virtual interface cards (VICs).
Special Considerations for Cisco UCS Fusion ioDrive2 Storage Accelerator Cards
Table 3-9 describes the requirements for the supported Cisco UCS Fusion ioDrive2 cards.
Ta b l e 3-8 Cisco UCS C220 Requirements for Virtual Interface Cards
Virtual Interface
Card (VIC)
Number of
VICs
S
upported
in
Server
Slots That
Support
VICs
1
1. See PCIe Slots, page 3-35.
Primary Slot For
UCS Integration
or Cisco Card
NIC Mode
Minimum
CIMC
Firmware
Minimum VIC
Firmware For
Use With UCS
Integration
Minimum Nexus
OS on an Upstream
Nexus Fabric
Interconnect
Cisco UCS VIC P81E
N2XX-ACPCI01
1 PCIE 1 PCIE 1 1.4(4) 2.0(2) 5.0
Cisco UCS VIC 1225
UCSC-PCIE-CSC-02
1 PCIE 1 PCIE 1 1.4(6) 2.1(0) 5.0
Cisco UCS VIC1225T
UCSC-PCIE-C10T-02
1 PCIE 1 PCIE 1
2
2. The Cisco UCS VIC1225T is not supported for UCS integration at this time.
1.5(1) 2.1(1) 5.0
Ta b l e 3-9 Cisco UCS C220 Requirements for Fusion ioDrive2 Cards
Card
Max. Number of
Cards Supported
Slots That
Su
pport Cards
1
1. See PCIe Slots, page 3-35.
Minimum CIMC
Firmware
Card Height 
(rear-panel tab)
Cisco UCS 3.0 TB MLC Fusion ioDrive2
UCSC-F-FIO-3000M
1 PCIE 1 1.5(2) Full height
Cisco UCS 1205 GB MLC Fusion ioDrive2
UCSC-F-FIO-1205M
2 PCIE 1
PCIE 2
2
2. Slot 2 is not available in single-CPU configurations.
1.5(2) Half height
3
3. A rear-panel tab adapter is required to fit the half-height cards in full-height slot 1.
Cisco UCS 785 GB MLC Fusion ioDrive2
UCSC-F-FIO-785M
2 PCIE 1
PCIE 2
1.5(2) Half height
Cisco UCS 365 GB MLC Fusion ioDrive2
UCSC-F-FIO-365M
2 PCIE 1
PCIE 2
1.5(2) Half height

Cisco UCS C220 M3 Specifications

General

Tcase	70 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor cache	10 MB
Processor cores	4
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor codename	Sandy Bridge EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	52.5 x 45.0 mm
Processor front side bus	- MHz
Processor boost frequency	2.50 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Graphics & IMC lithography	32 nm
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	24
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	750 GB
HDD size	2.5 \
HDD interface	-
Total storage capacity	500 GB
Compatible memory cards	SD
Maximum storage capacity	- TB
Memory slots	16
Internal memory	32 GB
Memory clock speed	1866 MHz
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Chassis type	Rack (1U)
Power supply	450 W
Safety	UL 60950-1 No. 21CFR1040, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, GB4943 2001
Certification	47CFR Part 15 (CFR 47), AS/NZS CISPR22, CISPR2 2, EN55022, ICES003, VCCI, EN61000-3-2, EN61000-3-3, KN22, CNS13438, EN55024, CISPR24, EN300386, KN24
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
PCI Express slots version	3.0
Processor ARK ID	64588
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	724 mm
Width	430 mm
Height	43.2 mm
