Appendix C RAID Controller Considerations
Embedded MegaRAID Controller
Step 4 Start the Windows driver installation using one of the following methods:
• To install from local media: Connect an external USB DVD drive to the server and then insert the
first Windows install disc into the drive. Skip to Step 6.
• To install from remote ISO: Log in to the server’s CIMC interface and continue with the next step.
Step 5 Launch a Virtual KVM console window and select the Virtual Media tab.
a. Click Add Image and browse to select your remote Windows installation ISO file.
b. Select the check box in the Mapped column for the media that you just added, then wait for mapping
to complete.
Step 6 Power cycle the server.
Step 7 Press F6 when you see the F6 prompt during bootup. The Boot Menu window opens.
Step 8 On the Boot Manager window, select the physical disc or virtual DVD and press Enter. The Windows
installation begins when the image is booted.
Step 9 Press Enter when you see the prompt, “Press any key to boot from CD.”
Step 10 Observe the Windows installation process and respond to prompts in the wizard as required for your
preferences and company standards.
Step 11 When Windows prompts you with “Where do you want to install Windows,” install the drivers for
embedded MegaRAID:
a. Click Load Driver. You are prompted by a Load Driver dialog to select the driver to be installed.
b. Connect the USB thumb drive that you prepared in Step 3 to the target server.
c. On the Windows Load Driver dialog that you opened in Step a, click Browse.
d. Use the dialog to browse to the location of the drivers folder on the USB thumb drive, and click OK.
Windows loads the drivers from the folder and when f
inished, the driver is listed under the prompt,
“Select the driver to be installed.”
e. Click Next to install the drivers.
Updating the Windows Driver
Perform the following steps to update the LSI MegaSR driver for Windows or to install this driver on an
existing system booted from a standard IDE drive.
Step 1 Click Start, point to Settings, and then click Control Panel.
Step 2 Double-click System, click the Hardware tab, and then click Device Manager. Device Manager starts.
Step 3 In Device Manager, double-click SCSI and RAID Controllers, right-click the device for which you are
installing the driver, and then click Properties.
Step 4 On the Driver tab, click Update Driver to open the Update Device Driver wizard, and then follow the
wizard instructions to update the driver.

Cisco UCS C220 M3 Specifications

General

Tcase	70 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor cache	10 MB
Processor cores	4
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor codename	Sandy Bridge EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	52.5 x 45.0 mm
Processor front side bus	- MHz
Processor boost frequency	2.50 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Graphics & IMC lithography	32 nm
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	24
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	750 GB
HDD size	2.5 \
HDD interface	-
Total storage capacity	500 GB
Compatible memory cards	SD
Maximum storage capacity	- TB
Memory slots	16
Internal memory	32 GB
Memory clock speed	1866 MHz
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Chassis type	Rack (1U)
Power supply	450 W
Safety	UL 60950-1 No. 21CFR1040, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, GB4943 2001
Certification	47CFR Part 15 (CFR 47), AS/NZS CISPR22, CISPR2 2, EN55022, ICES003, VCCI, EN61000-3-2, EN61000-3-3, KN22, CNS13438, EN55024, CISPR24, EN300386, KN24
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
PCI Express slots version	3.0
Processor ARK ID	64588
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	724 mm
Width	430 mm
Height	43.2 mm
