Cisco UCS C220 M3 Installation And Service Guide

1-4
Cisco UCS C220 Server Installation and Service Guide
OL-25760-01
Chapter 1 Overview
Network and
management I/O
The server provides these rear-panel connectors:
• One 1-Gb Ethernet dedicated management port
• Two 1-Gb Base-T Ethernet ports
• One RS-232 serial port (RJ-45 connector)
• One 15-pin VGA
4
connector
• Two USB
5
2.0 connectors
• One front-panel KVM connector that is used with the included KVM cable,
which provides two USB, one VGA, and one serial connector.
WoL The 1-Gb Base-T Ethernet LAN
ports support the wake-on-LAN (WoL) standard.
Power Up to two power supplies, both either 450W or 650W each. 
Redundant as 1+1. Do not mix power supply types in the server.
See Po
wer Specifications, page A-3 for more information on power supplies.
ACPI This server supports the advanced configuration and power interface (ACPI) 4.0
standard
.
Storage Drives are installed into front-panel drive bays that provide hot-pluggable access.
There a
re two versions of the server front panel and backplane:
• Small Form Factor—The server can hold up to eight 2.5-inch SAS
6
or SATA
7
hard drives or solid state drives.
• Large Form Factor—The server can hold up to four 3.5-inch SAS or SATA hard
drives.
The server also contains one int
ernal USB 2.0 port on the motherboard that you can
use with a USB thumb drive for additional storage.
Cisco Flexible
Flash drives
The server can be ordered with up to two opt
ional Cisco Flexible Flash drives (SD
cards).
This drive is pre-loaded with four virtual drives. The four virtual drives contain,
respect
ively, the Cisco Server Configuration Utility, the Cisco Host Upgrade Utility,
the Cisco C-Series server drivers set, and a blank virtual drive on which you can
install an OS or a hypervisor (see also Replacing a Cisco Flexible Flash Card,
page 3-40).
The two flash drives can be configured in a RAID 1 configuration to protect your
hy
pervisor VD.
Disk
Manag
ement
(RAID)
For a list of supported RAID controller options, see RAID Controller
Considerations, page C-1.
RAID Backup There is one mounting point inside the chassis that can be
used for a RAID backup
unit when using an LSI MegaRAID card. This unit can be either of the following:
• The optional LSI BBU that can be used with LSI MegaRAID cards.
• The SuperCap Power Module that can be used with LSI MegaRAID-CV cards.
Video Resolution up to 1600x1200, 16bpp at 60 Hz. Up to 256 MB of video memory.
1. DIMM = dual inline memory module
2. DDR3 = double data rate, type 3
3. PCIe = peripheral component interconnect express
4. VGA = video graphics array
5. USB = universal serial bus
Table 1-1 Cisco UCS C220 Server Features (continued)

Cisco UCS C220 M3 Specifications

General

Tcase	70 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor cache	10 MB
Processor cores	4
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor codename	Sandy Bridge EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	52.5 x 45.0 mm
Processor front side bus	- MHz
Processor boost frequency	2.50 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Graphics & IMC lithography	32 nm
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	24
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	750 GB
HDD size	2.5 \
HDD interface	-
Total storage capacity	500 GB
Compatible memory cards	SD
Maximum storage capacity	- TB
Memory slots	16
Internal memory	32 GB
Memory clock speed	1866 MHz
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Chassis type	Rack (1U)
Power supply	450 W
Safety	UL 60950-1 No. 21CFR1040, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, GB4943 2001
Certification	47CFR Part 15 (CFR 47), AS/NZS CISPR22, CISPR2 2, EN55022, ICES003, VCCI, EN61000-3-2, EN61000-3-3, KN22, CNS13438, EN55024, CISPR24, EN300386, KN24
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
PCI Express slots version	3.0
Processor ARK ID	64588
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	724 mm
Width	430 mm
Height	43.2 mm
