Cisco UCS C480 M5 Memory Guide
22
Memory Capacities for CPU Classes
Mixed DIMM/DCPMM Configurations
This section describes the memory capacities for configurations that use a combination of DIMMS and
DCPMMs.
DIMM/DCPMM Configurations for 2
nd
Generation Intel
®
Xeon
®
Scalable Processors
Table 15, Table 16, and Table 17 show the possible configurations for 2nd Generation Intel® Xeon®
Scalable Processors populated with combinations of DIMMs and DCPMMs. When DCPMMs are selected, there
must be 6 DIMMs per CPU and can be 2, 4, or 6 DCPMMs per CPU, depending on CPU class (“M”, “L”, or
regular class) and DCPMM capacity. Selection of DCPMMs also requires that all CPUs be fully populated. The
tables below show configurations for 1 CPU. For Memory Mode and Mixed Memory Mode, the
Intel-recommended DIMM to DCPMM capacity ratio for the same CPU is from 1:4 to 1:16. The green-shaded
cells of the table indicate ratios within that range, while the red-shaded portions indicate ratios outside
that range. For App Direct Mode, the ratio requirement does not apply.
App Direct Mode
The following tables apply to the App Direct Mode. For App Direct Mode, the DIMM to DCPMM ratio
requirement does not apply.
Table 15 2nd Gen “M” CPU DIMM/DCPMM Memory (6 DIMMs per CPU, and 2, 4, or 6 DCPMMs per CPU)
Number of
DIMMs
1
/DCPMMs
per CPU
Capacity Per DIMM (GB)
16 32 64 128
256
2
Capacity Per DCPMM (GB) 128 128 128 128 128
6 DIMMs 96 192 384 768 1536
2 DCPMMs 256 256 256 256 256
Total Capacity per CPU 352 448 640 1024 1792
Capacity Per DCPMM (GB) 256 256 256 256 256
6 DIMMs 96 192 384 768 1536
2 DCPMMs
512 512 512 512 512
Total Capacity per CPU 608 704 896 1280 2048
Capacity Per DCPMM (GB) 512 512 512 512 512
6 DIMMs 96 192 384 768 N/A
2 DCPMMs 1024 1024 1024 1024 N/A
Total Capacity per CPU 1120 1216 1408 1792 N/A
