Cisco UCS C480 M5 Guide

Cisco UCS C480 M5 Memory Guide
Memory Capacities for CPU Classes
29
Capacity Per DCPMM (GB) 256 256 256 256 256
DIMM:DCPMM capacity
ratio per CPU
1:16 1:8 1:4 1:2 1:1
6 DIMMs 96 192 384 768 1536
6 DCPMMs
1536 1536 1536 1536
1536
Total Capacity per CPU 1632 1728 1920 2304
3072
Capacity Per DCPMM (GB) 512 512 512 512 512
DIMM:DCPMM capacity
ratio per CPU
1:32 1:16 1:8 1:4 1:2
6 DIMMs 96 192 384 768 1536
6 DCPMMs
3072 3072 3072 3072
3072
Total Capacity per CPU 3168 3264
3456 N/A N/A
NOTE: The cells marked with N/A indicate a memory capacity that would be more
than the allowable 3584 GB and therefore cannot be configured.
Notes:
1. If DCPMMs are selected, 6 DIMMs per CPU must also be selected
2. 256 GB DIMMs are available in CQ4'CY2019
Table 18 2nd Gen “M” CPU DIMM/DCPMM Memory (6 DIMMs per CPU, and 2, 4, or 6 DCPMMs per CPU)
Number of
DIMMs
1
/DCPMMs
per CPU
Capacity Per DIMM (GB)
16 32 64 128
256
2
